AVR DX-11 GENERATOR BRUSH DX11  KARBON BRUSH DX 11 - AVR GB130 DX-11 G

AVR DX-11 GENERATOR BRUSH DX11 KARBON BRUSH DX 11 - AVR GB130 DX-11 GB 130 DX11 GB130 DX 11

Model = DX-11 : GB130 DX-11 (Same Product 100%)
Description = AVR Generator Brush
Sensing/Power input Voltage = 400V AC, 1 phase 2 wire
Frequency = 50-60 Hz nominal
Magnetic Field Output
Current = 20A
Resistance = 15 ohms minimum

Brush Generator AVR Circuit Diagram GB-130 is a single phase controlled Thyristor type Automatic Voltage Regulator and forms part of the excitation system for a brush generator. In addition to regulating the generator voltage, the AVR circuitry includes under speed and sensing loss protection to ensure safe, reliable control of the generator.
Positive voltage build up from residual levels is ensured by the use of proficient semiconductors in the power circuitry of the AVR. Which is linked with the main stator windings and the exciter field windings to offer closed loop control of the output voltage with load regulations of +/- 1.5%
